697-2RS Ball Bearing 7x17x5 mm 697 2RS Rubber Sealed
697-2RS Ball Bearing 7x17x5 mm 697 2RS Rubber Sealed
697-2RS Ball Bearing 7x17x5 mm 697 2RS Rubber Sealed

697-2RS Ball Bearing 7x17x5 mm 697 2RS Rubber Sealed

: In stock

: Ball Bearings

: MAPLE ACE

$1.20 USD

  • 697 2RS Deep Groove Ball Bearing dimensions: Bore Diameter 7mm, Outside Diameter 17mm, Width 5mm. It is made of 100% Chrome Steel and Pre-Lubricated with High-Quality Grease, ideal for use in High, and Low-temperature settings.
  • Interchange to 697, 697 RS, 697 RSR, 697 2RSR, 697 RSH, 697 2RSH, 697 2RSJEM, 697 LU, 697 LLU, 697 DU, 697 DDU, 697 2NSL, 697 2NSE, 697 EE
  • This deep groove ball bearing has a rubber seal on both sides connected to the inner ring to stop dust from entering. If your application requires a ball bearing with one seal or opened without seals, you can easily remove one or both seals.
  • Application: 3D Printer, Bicycle, Hobby and Recreation Bearing, RC Car, Vacuum, Fishing Reel, Automotive, Appliances, Sporting Machines, Agriculture Machines, Industrial Applications, Electric Motors, HVAC, Furnaces, Transmissions, Gearboxes, Elevators, Lifts and Hoists, Medical Devices...etc
  • Specializing in the Exclusive Production of Bearings with High Performance, High Speed, Less Vibration, Low Noise, and Long Life.
Add to wishlist

Description

  • Single-row deep groove ball bearings with seals or shields on one or both sides are particularly versatile.
  • They feature low friction and are optimized for:
    • Low noise
    • Low vibration
    • High rotational speeds
  • Capable of accommodating both radial and axial loads in both directions.
  • Easy to mount, requiring less maintenance compared to other bearing types.
  • The integral sealing system prolongs bearing service life by:
    • Keeping lubricant inside the bearing
    • Preventing contaminants from entering the bearing

Item697-2RS
Bore Diameter7.00 mm
Outside Diameter17.00 mm
Width, Total5.00 mm
Width, Inner Ring5.00 mm
Width, Outer Ring5.00 mm
Basic Dynamic Load Rating (Cr)1.06 kN
Basic Static Load Rating (C₀r)0.375 kN
Limiting Speed26,000 r/min
Rolling ElementBall
Number of Rows1
Locating Feature (Outer Ring)None
Bore TypeCylindrical
Cage MaterialSheet metal
Radial Internal ClearanceCN
Tolerance ClassP6
Bearing MaterialGCr15
SealingSeal on both sides
Sealing TypeContact
LubricationGrease
Relubrication FeatureWithout
Product Weight5.4 g
FAG 697-2RSR
INA 697-2RSR
SKF 619/7-2RS1

You can use this MINIATURE DEEP GROOVE BALL BEARING as a Replacement Part for:

  • Automotive
  • Turbo-machinery Pumps
  • Industrial
  • Miniature Motor
  • Textile
  • Fuel Control
  • Flow Meter
  • Office equipment
  • Paper-making machine
  • 3D Printer
  • Medical Handpieces & Instruments
  • Surgical Devices
  • Robots, Bicycle
  • Fishing Reel
  • Slip Ring
  • Hobbies
  • RC Car & Truck
  • RC Engine
  • RC Helicopter
  • Slot Car
  • YoYo
  • Fidget Spinner
